Technical Specification- TITAN
Tkt	Tex	Denier/Ply	Breaking Strength (Gms)	Elongation % Min- Max	Recommended Needles (NM)
180	16	70/3	1,050	15 – 30	70 - 80
80	35	100/3	2,100	15 – 30	75 - 100
80	30	150/2	2,000	15 – 30	75 - 100
60	45	150/3	3,000	15 – 30	85 - 110
60	45	210/2	2,700	15 – 30	85 - 110
50	60	170/3	3,500	15 – 30	85 - 110
40	70	210/3	4,100	15 – 30	95 - 120
30	90	250/3	5,200	15 – 30	110 - 130
20	135	420/3	8,000	15 – 30	120 - 140
16	150	500/3	10,000	15 – 30	130 - 160
12	240	250/9	16,000	15 – 30	130 - 160
10	270	840/3	18,000	15 – 30	160 - 200
8	350	1000/3	21,000	15 – 35	180 - 230
7	450	1000/4	25,000	15 – 35	210 - 250
6	500	1500/3	31,000	15 – 35	240 - 280
5	600	1500/4	40,000	15 – 35	240 - 280

Technical Specification- FALCON
Tkt	Tex	Denier/Ply	Breaking Strength (Gms)	Elongation % Min- Max	Recommended Needles (NM)
180	16	70/3	1,050	15 – 30	70 - 80
80	35	100/3	2,100	15 – 30	75 - 100
80	30	150/2	2,000	15 – 30	75 - 100
60	45	150/3	3,000	15 – 30	85 - 110
60	45	210/2	2,700	15 – 30	85 - 110
50	60	170/3	3,500	15 – 30	85 - 110
40	70	210/3	4,100	15 – 30	95 - 120
30	90	250/3	5,200	15 – 30	110 - 130
20	135	420/3	8,000	15 – 30	120 - 140
16	150	500/3	10,000	15 – 30	130 - 160
12	240	250/9	16,000	15 – 30	130 - 160
10	270	840/3	18,000	15 – 30	160 - 200
8	350	1000/3	21,000	15 – 35	180 - 230
7	450	1000/4	25,000	15 – 35	210 - 250
6	500	1500/3	31,000	15 – 35	240 - 280
5	600	1500/4	40,000	15 – 35	240 - 280

Technical Specification- PULSAR
Tkt	Tex	Denier/Ply	Breaking Strength (Gms)	Elongation % Min- Max	Recommended Needles (NM)
80	35	100/3	2,200	15 – 32	75 - 100
60	45	150/3	3,000	15 – 32	80 - 100
60	45	210/2	3,290	15 – 32	80 - 100
40	70	210/3	5,000	15 – 32	95 - 120
30	90	210/4	6,800	15 – 32	100 - 130
20	135	420/3	10,000	15 – 32	120 - 140
15	210	630/3	15,000	17 – 35	130 - 160
10	270	840/3	20,000	17 – 35	160 - 200
8	350	1000/3	21,000	17 – 35	160 - 230
7	450	1000/4	25,000	17 – 35	210 - 250
6	500	1500/3	31,000	17 – 35	210 - 250

Technical Specification- SPIRIT
Tkt	Tex	Denier/Ply	Breaking Strength (Gms)	Elongation % Min- Max	Recommended Needles (NM)
60	45	210/2	2,850	16 – 35	80 - 110
40	70	210/3	4,000	16 – 35	90 - 120
30	90	210/4	5,500	16 – 35	100 - 130
20	135	420/3	8,000	16 – 35	120 - 140
15	210	630/3	12,000	16 – 35	130 - 160
10	270	840/3	16,000	16 – 35	160 - 200
8	350	1260/3	24,000	16 – 35	180 - 230

Technical Specification- QUASAR
Tkt	Tex	Denier/Ply	Breaking Strength (Gms)	Elongation % Min- Max	Recommended Needles (NM)
80	35	100/3	2,200	15 – 30	75 - 100
60	45	150/3	3,000	15 – 30	85 - 110
60	45	210/2	3,300	15 – 30	85 - 110
40	70	210/3	5,000	15 – 30	95 - 120
30	90	210/4	6,800	15 – 30	110 - 130
20	135	420/3	10,000	17 – 32	120 - 140
15	210	630/3	15,000	17 – 32	130 - 160
10	270	840/3	20,000	20 – 35	160 - 200
8	350	1000/3	21,000	20 – 35	180 - 230
7	450	1000/4	25,000	20 – 35	210 - 250
6	500	1500/3	31,000	20 – 35	240 - 280
5	600	1500/4	40,000	20 – 35	240 - 280

Technical Specification- STALLION
Tkt	Tex	Denier/Ply	Breaking Strength (Gms)	Elongation % Min- Max	Recommended Needles (NM)
80	35	100/3	2,200	17 – 32	75 - 100
60	45	150/3	3,000	17 – 32	85 - 110
60	45	210/2	3,300	17 – 32	85 - 110
40	70	210/3	5,000	17 – 32	95 - 120
30	90	210/4	6,800	17 – 32	110 - 130
20	135	420/3	10,000	17 – 32	120 - 140
15	210	630/3	15,000	17 – 32	130 - 160
10	270	840/3	20,000	20 – 35	160 - 200
8	350	1000/3	21,000	20 – 35	180 - 230
7	450	1000/4	25,000	20 – 35	210 - 250
6	500	1500/3	31,000	20 – 35	240 - 280
5	600	1500/4	40,000	20 – 35	240 - 280

Technical Specification- NEBULA
Tkt	Tex	Denier/Ply	Breaking Strength (Gms)	Elongation % Min- Max	Recommended Needles (NM)
270	11	100/1	430	20 - 35	65 - 80
180	16	150/1	610	20 - 35	70 - 80
110	24	200/1	900	20 - 35	80 - 90
90	35	300/1	1200	20 - 35	85 - 110
80	35	150/2	1240	20 - 35	85 - 110
50	50	150/3	1850	20 - 35	90 - 110
35	60	150/4	2500	20 - 35	110 - 130

Technical Specification- ORION
Tkt	Tex	Denier/Ply	Breaking Strength (Gms)	Elongation % Min- Max	Recommended Needles (NM)
380	8	70/1	375	20 - 35	60 - 80
190	15	70/2	750	20 - 35	60 - 80
240	12	100/1	450	20 - 35	60 - 80
120	24	100/2	900	20 - 35	70 - 100
180	16	150/1	650	20 - 35	70 - 90
80	35	150/2	1350	20 - 35	85 - 110

Technical Specification- HELIX
Tkt	Tex	Denier/Ply	Breaking Strength (Gms)	Elongation % Min- Max	Recommended Needles (NM)
180	15	70/2	700	18 - 30	60 - 80
120	27	115/2	1225	18 - 30	70 - 100
120	27	120/2	1275	18 - 30	70 - 100
60	50	230/2	2500	18 - 30	85 - 110

Technical Specification- VEGA
Tkt	Tex	Denier/Ply	Breaking Strength (Gms)	Elongation % Min- Max	Recommended Needles (NM)
10	300	840/3	19000	18 - 30	160 - 200
15	220	630/3	15000	18 - 30	130 - 160
27	111	500/2	6500	18 - 30	110 - 130
40	70	210/3	4500	18 - 30	95 - 120
